Rubycon Polymer Hybrid

Rubycon Updates on Polymer Hyprid Capacitors

17. April 2019

The Japanese capacitor specialist Rubycon announces an upgrade of several series of SMD polymer hybrid capacitors. The PFV series (Load life: 4000h at 125 °C) has been extended by the operating voltage 80V. The PJV series (Load life: 4000h at 125 °C, High capacity) is now available with 50V and 63V operating voltages. For example, […]

> Read more
Wide Terminal

WK73 from KOA – Thick Film Wide Terminal Type with new sizes

22. January 2019

KOA has extended the WK73 series by several sizes. For the WK73R (resistance ≥ 10 Ohm), three sizes are added, namely 0508, 0306 and 0204. The WK73S (resistance <10 Ohm) has been extended by size 0508. For size 0508 the rated power is spezified up to 1 Watt, for 0306 to 0.5 Watt and for […]

> Read more
RS73

RS73 – High Precision and High Reliability

8. June 2018

KOA’s new RS73-series is designed for high precision and high reliability applications by using thick film technology. With a T.C.R. down to 25ppm and a tolerance as low as 0.1%, the new RS73-series from KOA is ideal for precision designs such as high-accuracy sensing or voltage detection circuits in automotive, industrial and measuring applications, where […]

> Read more
SG73G Impulsfest

SG73G – Pulse Proof High Precision Resistor from KOA

25. January 2018

KOA now offers an advanced version of the proven SG73P-series. The Thickfilm SG73G-series is characterized by low resistance tolerance (0.5% or 0.25%) and a low TK (±50 ppm/K). This is possible because KOA optimized the resistive material and the production process. The SG73G-series has the same one-pulse characteristics as the SG73P-series. Until now three sizes […]

> Read more
WK73 High Power

WK73 from KOA – High Power Thick Film Wide Terminal Type

8. January 2018

KOA offers now a Power up version of its proven WK73 series. Using the concept of Terminal Part Temperature, Power Ratings of 1.5 Watt (size 0612), 2 Watt (size 1020) and 3 Watt (size 1225) are possible. In every case the derating starts at 95°C. Outstanding features of this component are excellent heat dissipation characteristics […]

> Read more

Current Sensing Thick Film Resistors for Automotive from KOA

11. April 2017

KOA’s UR73V-series thick film low ohm resistors are designed for current detection, especially in demanding environments. The special facedown construction makes lower resistance values with a low T.C.R. of ±75 ppm/K possible. The low T.C.R of new UR73V-series and its wide operating temperature range of -55 °C to +155 °C make it ideal for applications […]

> Read more
KOA High Power Shunt

KOA expands Shunt Portfolio

15. November 2016

With the new series PSJ2 and PSG4 current sensing resistors, KOA is expanding its range of Metal Plate Power Shunts. The four-pole design of the PSG4 in size 2725inch with welded copper connections makes a high current of up to 140 A possible. These low-resistance, non-inductive power resistors are available in the ohm values 0.5 […]

> Read more
KOA Resistor

High precision thick film resistor from KOA

23. March 2016

Now it is not necessary anymore to take a resistor in thinfilm technology if a resistor tolerance of 0,25% is used. Compared to KOA´s general purpose RK73-series, the new RK73G-series has an even better T.C.R of 50 ppm/K and its low resistance tolerance of 0,25% is ideal for precision designs. The RK73G-series in the new […]

> Read more
Wide Terminal

WU73 from KOA – Thick Film Wide Terminal Type with low TCR

23. December 2015

In expansion of the WK73 series KOA offers now the WU732B. This low ohm resistor with longitudinal terminations provides at a size of 0612 and Tol. 1% a rated power of 1 Watt. The component produced in thick film technology is available in a resistance range of 10 mOhm to 100 mOhm. It is characterized […]

> Read more
Shunt KOA

New 5 Watt shunt resistor from KOA

25. September 2015

The SL-series from KOA is now with a power rating of 5 Watt available. The size of the SLN5 is 4528, the value range is from 5 to 9,1 mOhm (TCR 110 ppm/K) resp. from 10 to 200 mOhm (TCR 75 ppm/K). The wide temperature range extends up to 180ᵒC, the derating starts only at […]

> Read more
